Tomos A3 handle bar

1 219920 THROTTLE CPL.-NOT AVAILABLE

2 222602 SEE 234.501

3 222601 BRAKE LEVER R.-BLACK

4 213652 BREAST BOLT

4 213652 BREAST BOLT

4 213652 BREAST BOLT

4 213652 BREAST BOLT

5 30048 NUT M5 SELF-LOCKING

5 30048 NUT M5 SELF-LOCKING

6 222606 RESSORT D

7 27079 FISH M6 X 16

7 27079 FISH M6 X 16

7 27079 FISH M6 X 16

8 206790 CHOKEPAL-NOT AVAILABLE

8 206790 CHOKEPAL-NOT AVAILABLE

9 222608 SWIVEL BUSH

10 213654 BARILLET

10 213654 BARILLET

10 213654 BARILLET

10 213654 BARILLETTE

11 219922 SEE 229.552

12 222600 BRAKE LEVER L. BLACK

13 222605 RESSORT G

14 222603 SEE 229.554

15 222842 THROTTLE CABLE

16 222944 REAR BRAKE CABLE

17 222843 FRONT BRAKE CABLE

18 206423 THROTTLE HANDLE CPL.-NOT AVAILABLE

18 217828 THROTTLE HANDLE-NOT AVAILABLE

19 206788 THROTTLE HAND LEVER HEAD

20 206789 BUSHING-NOT AVAILABLE

21 205493 LOCKING BOLT

22 31973 RONDELLE RESSORT A5

22 31973 RONDELLE RESSORT A5

23 31074 NUT M5

23 31074 NUT M5

24 205497 PLATE-NOT AVAILABLE

25 205491 PLATE-NOT AVAILABLE

26 31075 NUT M6

27 204200 BRAKE LEVER R.

28 213651 BRAKE LEVER R.

29 206429 BRAKE LEVER CPL.-SILVER-NOT AVAILABLE

29 217829 BRAKE HANDLE L.-NOT AVAILABLE

30 211,674.00 € BRAKE LEVER L.

31 213,656.00 € BRAKE LEVER L.

32 217437 HANDLE L-BLACK

33 217438 HANDLE R-BLACK

34 213866 BEL. RIGHT MODEL

35 207248 HANDLEBAR-NOT AVAILABLE

35 214810 HANDLEBAR-CHROME

36 207249 HANDLEBAR STEM-NOT AVAILABLE

37 207595 SEE 223.003

37 223003 HANDLEBAR-CHROME

38 209199 THROTTLE CABLE
