Tomos A3 ignition (Iskra 12V-50W)

1 215487 NUT M10 X 1

2 31934 WASHER 10

3 200048 GUIDE 3 X 5

4 204278 CAPACITOR

5 222042 SEE 223.176

6 222043 SEE 223.162

7 31507 WASHER 4

7 31507 WASHER 4

8 31999 CIRCLIP J4

8 31999 CIRCLIP J4

8 31999 CIRCLIP J4

9 27205 BOLT M4X14

10 27053 BOLT M4X10

11 27058 BOLT M4X25

12 222045 SEE 223.170

13 222046 SEE 223.169

14 204277 SEE 223.164

15 219509 SEE 220.962

16 210175 TULE

16 210175 TULE

17 44528 CABLE D'ALLUMAGE AU METRE

18 221038 VOLTAGE REGULATOR (12 VOLTS)

19 211977 SPARK PLUG CAP

20 222237 IGNITION COIL SUPPORT

21 27063 BOLT M5X8

22 31844 SPRING WASHER B5

22 31844 SPRING WASHER B5

23 31074 NUT M5

24 27066 BOLT M5X16

25 27068 BOLT M5X20

26 31845 SPRING WASHER B6

27 27082 BOLT M6X25

Parts 4 - 14 222010 INSTALLING CPL
