Tomos A3 ignition (CEV 12V-50W)

1 221311 FLYWHEEL

2 221312 BASE PLATE CPL

2 221313 BASE PLATE

3 221314 POWER COIL

4 221315 LIGHT COIL

5 27058 BOLT M4X25

6 31507 WASHER 4

7 221309 CONTACT SET

8 221310 CAPACITOR

9 27053 BOLT M4X10

9 27053 BOLT M4X10

10 221014 NUT M10X1

11 31934 WASHER 10

12 200048 GUIDE 3 X 5

13 27205 BOLT M4X14

14 31999 WASHER J4

15 31866 WAVE WASHER 4

15 31866 WAVE WASHER 4

16 211975 SEE 229.006

17 211977 SPARK PLUG CAP

18 210175 TULE

19 27066 BOLT M5X16

20 31844 SPRING WASHER B5

20 31844 SPRING WASHER B5

21 31074 NUT M5

22 221038 VOLTAGE REGULATOR (12 VOLTS)

23 31995 RONDELLE RESSORT A6

24 27082 BOLT M6X25

25 27063 BOLT M5X8

26 222237 COIL SUPPORT

27 27068 BOLT M5X20

Parts 1 - 9 221005 FITTING CPL
