Tomos A3 ignition (Iskra 6V 17W, 6V 20W)

1 215487 NUT M10 X 1

2 31934 WASHER 10

3 200048 GUIDE 3 X 5

4 204278 CAPACITOR

5 204274 FLYWHEEL

5 219426 FLYWHEEL

6 204279 BASE PLATE

7 31507 WASHER 4

7 31507 WASHER 4

7 31507 WASHER 4

8 31999 WASHER J4

9 27205 BOLT M4X14

10 27053 BOLT M4X10

11 204275 IGNITION COIL

12 31843 SPRING WASHER B4

12 31843 SPRING WASHER B4

12 31843 SPRING WASHER B4

13 27057 FISH M4 X 20

14 44528 CABLE D'ALLUMAGE AU METRE

15 204276 LIGHT COIL

16 27058 BOLT M4X25

17 204277 SEE 223.164

18 201019 SPARK PLUG CAP

19 205014 RUBBER GROMMET

Parts 4 - 17 214650 SEE 223.160

Parts 4 - 17 219444 FUSE CPL
