Tomos Flexer frame (with plastic rear mudguard)

1 232543017 FRAME-BRIGHT RED

2 232543020 FRAME-BLACK

3 209141 BUSHING FRAME

4 232546 TANK CAP

5 232547 FUEL TAP

6 44531 FUEL HOSE PER METRE

7 224056 HOSE CLAMP

8 232549 VENT BUTTON

9 232553 BREATHER BUTTON

10 232552 BOUT

11 229094 CENTRE STAND

12 200609 STANDARD SPRING

13 209143 BRACKET FOR STANDARD SPRING

14 26041 BOLT M8X65

15 31933 WASHER 8

16 30049 NUT M8X1-SELF-LOCKING

17 229786017 REAR FORK RED

18 229786020 REAR FORK BLACK GLOSSY 801

19 209144 BEARING BUSH

20 26083 BOLT M12X1,25X120

21 31935 WASHER 12

22 31997 CIRCLIP A12

23 31126 SEE 030051

24 232559 SHOCK ABSORBER (BLACK SPRING)

25 25409 SOCKET BOLT M10X35

26 211597 WASHER

27 232564017 FOOT STRUT SUPPORT BRIGHT RED

28 232564020 FOOT SUPPORT CARRIER BLACK

29 232623 FOOT SUPPORT

30 232624 FOOTREST CPL.

31 232568 FOOTREST RUBBER

32 26594 SOCKET BOLT M10X25

33 31848 WASHER B10

34 232572 FRONT MUDGUARD-NOT AVAILABLE

35 26554 SOCKET SCREW M5X16

36 31931 RONDELLE 5

37 31973 RONDELLE RESSORT A5

38 31074 NUT M5

39 232573 REAR MUDGUARD

40 31509 WASHER 6

41 30040 NUT M6 SELF-LOCKING

42 232582 COVER PLATE

43 44418 PARKER 4.2X13

44 207462 SEE 234323

45 217807 Unknown part

46 27259 BOLT M5X8

47 30048 NUT M5-SELF-LOCKING

48 31931 RONDELLE 5

49 31973 RONDELLE RESSORT A5

50 31074 NUT M5

51 234517 TANK DECAL SET FLEXOR-ORANGE

52 234507 DECAL SET CPL. FLEXER
